Ortur Laser Master 3 - Laser Cutter & Engraver (10W)
A compact, light weight & portable 10W laser cutter and engraver for hobbyists, capable of engraving at speeds of up to 20,000mm/min and capable of cutting up to 8mm acrylic in...
A compact, light weight & portable 10W laser cutter and engraver for hobbyists, capable of engraving at speeds of up to 20,000mm/min and capable of cutting up to 8mm acrylic in one pass!
Features
 |
10W Laser Module4th generation of laser spot compression technology and 2nd generation of laser diode combining technology allow the Ortur Laser Master 3 to have a true 10W output! |
High PrecisionCompared to other 10W laser cutters & engravers, the Ortur Laser Master 3 has a superior laser head design resulting in a smaller focal spot of 0.05 x 0.1mm which allows you to capture delicate details in your projects. |
 |
 |
Safety FeaturesThousands of tests were conducted to ensure safe operation at all times!
|
ConnectionsThe Ortur Laser Master 3 can be connected via USB to a computer for use with softwares such as LightBurn and LaserGRBL or it can be connected to a mobile phone or tablet via Wi-Fi for use with the Laser Explorer app! |
 |
 |
Rotary CompatibleNot only can you engrave on flat objects, you can also engrave on cylindrical! A YRR switch can be found at the top of the machine which once switched allows you to connect a rotary attachment and engrave on cylindrical objects. |
Powerful 10W Laser
8mm Wood Cut in 1 Pass
20mm Maximum Cutting Thickness - Pine Wood
8mm Acrylic Cut in 1 Pass
30mm Maximum Cutting Thickness - Acrylic
Compatible Software
Ortur has spoilt you when it comes to software as the Laser Master 3 is not only compatible with one software but three!
Laser Explorer
A professional yet easy to use app compatible with iOS and Android smartphones and tablets.
LightBurn
An advanced and highly customisable software compatible with Windows XP and up, Linux & Mac OS.
LaserGRBL
Basic and easy to use software compatible with Windows XP and up & Linux.
Contents
- Machine Size: 588 x 660 x 150mm
- Weight: 6.5kg
- Working Area: 400 x 400mm
- Engraving Speed: 0-20,000mm/min
- Output Power: 9.5-10.5W
- Electrical Power: 40W
- Laser Wavelength: 455±5nm
- Spot Size: 0.05 x 0.1mm
- Spot Mode: Square Spot
- Focal Distance: 50mm
- Laser Level: Class IV
- Available Luminous Power: LU2-10A (9500-105400mw)
- Service Life: >10,000h
- Connection: Wi-Fi | APP | USB | SD Card
- Accepted File Formats: JPG | JPEG | PNG | BMP | SVG | etc.
- Control Software: LaserGRBL | LightBurn | Laser Explorer (App)
What materials can the Ortur Laser Master 3 cut and engrave?
| Material | Thickness | Engraved | Cut |
|---|---|---|---|
| MDF | 5mm | Yes | Yes |
| Plywood | 10mm | Yes | Yes |
| Pine Wood | 19mm | Yes | Yes |
| Paulownia Plank | 15mm | Yes | Yes |
| Cardboard - Gray | 6mm | Yes | Yes |
| Cardboard - White | 5mm | Yes | Yes |
| Corrugated Board | 6mm | Yes | Yes |
| Acrylic - Black | 30mm | Yes | Yes |
| Leather | 2mm | Yes | Yes |
| A4 Paper | - | Yes | Yes |
| Cotton | - | Yes | Yes |
| Bamboo | - | Yes | Yes |
| Cork Coaster | - | Yes | No |
| Cobblestone | - | Yes | No |
| Glass | - | Yes | No |
| Rubber | - | Yes | No |
| Stanless Nameplate | - | Yes | No |
| Stainless Steel | - | Yes | No |
| Scratch Paper | - | Yes | No |
| Ceramics (laser colour paper on it) | - | Yes | No |
| Coated Metal Card | - | Yes | No |
